Electric Steam Boiler Manufacturer
Electric Steam Boiler Price
An electric steam boiler is a type of boiler that uses electricity as its power source to heat water and generate steam. It is commonly used in industrial applications where steam is required for heating, process, or power generation.
Electric steam boilers work by using an electric heating element to heat water in a pressure vessel, typically made of stainless steel or other suitable materials. The heating element is energized by an electrical power source, which heats the water to its boiling point, producing steam. The steam is then released from the boiler and used for various applications.
One of the main advantages of electric steam boilers is their efficiency, as they do not require the burning of fossil fuels, which can result in lower emissions and reduced environmental impact. Electric steam boiler manufacturers are also relatively easy to install and operate, and they can be used in a wide range of applications, from small-scale operations to large industrial processes.
Features of Electric Steam Boiler
- Fully automatic operation
- Packaged unit
- Non-IBR design
- Pollution free steam generation
- Multiple safety features
- Compact size
- Silent operation
- Clean and pure steam
- Stainless steel (SS 304) pressure vessel
- Thick insulation to prevent heat loss
- Long life SS 316 heating elements
- Sturdy construction
- Automatic feed water controller with pump
- Steam control through steam pressure
- Steam control through steam temperature
- High quality electrical for control panel
Our Products
Fill The Form
Electric Steam Boiler Specifications
| Manufacturer | Model | Power (kW) | Steam Output (kg/hr) | Max Pressure (bar) | Voltage (V) | Automation Grade | Material | Features |
|---|---|---|---|---|---|---|---|---|
Steamax Energy India | Model S | 12 to 2250 | up to 7875 | 15-250 psig | up to 600 | Automatic | Insulated Vessel | Zero emissions, nearly 100% efficiency, compact design |
Steamax Energy India | ES-9* | 9 | 13 | 7 | 220/440 | Automatic | SS304/SS316 | Fully automatic, non-IBR design, compact size |
Steamax Energy India | ES-18 | 18 | 25 | 7 | 220/440 | Automatic | SS304/SS316 | Multiple safety features, silent operation |
Steamax Energy India | ES-27 | 27 | 38 | 7 | 220/440 | Automatic | SS304/SS316 | Long life heating elements, sturdy construction |
Steamax Energy India | 9 kW Automatic Steam Boiler | 9 kW | 15 kg/hr (approx) | 5 kg/cm² | 220V (3-Phase) | Automatic | Mild Steel | Compact design, pollution-free steam generation |
Steamax Energy India | 16 kg/hr | 0-10 kg/cm² | 220V | Automatic | Mild Steel | High safety features, automatic pressure control | ||
Steamax Energy India | ELSB | 350 to 7500 kg/hr | up to 24 bar | Electric | Automatic | Various materials available | CO2-neutral steam supply, smart boiler control |
